High Density 5mm Matt White Pet Expandable Cable Braided Sleeve For Wire Protection
1. Description of pet expandable braided sleeve
Expandable sleeving is braided by environment-friendly polyester monofil
(PET,PA6,PA66,PPS).
Working temperature: -50℃~150℃
Melting point: 250℃±5
Flame resistant grade:UL VW-1
2. Characteristics
1). Flexibility, fire resistance, abrasive resistance and thermal insulation performance ;
2). The sleeving owns smooth surface, bright color, various patterns ;
3). Working temperature: -50℃~150℃
4). Melting point: 250℃±5
5). Flame resistant grade:UL VW-1
6). Standard color: Black color
Feature of pet expandable braided sleeving
1. Strong corrosion resistance,excellent flexibility, easy bending, simplify operation, good scalability, resilience and abrasion resistance.
2. Application:Products are widely used in computer power cord, audio-video, automotive, aviation, wire and cable industries. It has protect and beautify the role. Its unique mesh characteristics but also has good ventilation, and a thermal diffusion function in a timely manner.
3. Notes:
PET expandable sleeving in expanding at the same time can be shorten, about 30%, please reserve enough length.
Huiyunhai polyester expandable sleeving is flame-retardant and halogen-free. It offers durable abrasion resistance in a wide range of industrial applications. The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors.
Totally expanded the sleeving can reach at least 1.5 times than the initial dimension.
Huiyunhai nylon expandable sleeving is made of nylon 6.6 monofilament which offers excellent performance of abrasion resistance. It is lightweight , highly flexible and it can resists to many chemicals agents. Uniquely shaped monofilament provides smooth, soft, slick surface resisting snags when dragged over rough surface.
Specification for braided sleeves
Nominal
Size | Product
Part # | Expansion Range | Spool Put-Ups |
| | | Min. | Max. | Bulk | Shop |
1/16"
1/8"
1/4"
3/8"
1/2"
5/8"
3/4"
1"
1 1/4"
1 1/2"
1 3/4"
2"
2 1/2"
3" | CBS0.06
CBS0.13
CBS0.25
CBS0.38
CBS0.50
CBS0.63
CBS0.75
CBS1.00
CBS1.25
CBS1.50
CBS1.75
CBS2.00
CBS2.50
CBS3.00 | 3/64"
3/32"
1/8"
3/16"
1/4"
3/8"
1/2"
5/8"
3/4"
1"
1 1/4"
1 1/2"
1 3/4"
2 1/2" | 3/32"
1/4"
7/16"
1/2"
3/4"
1"
1 1/4"
1 5/8"
1 3/4"
2 1/8"
2 3/4"
3 1/2"
3 5/8"
4 3/4" | 1,000'
1,000'
1,000'
500'
500'
500'
250'
250'
250'
200'
200'
200'
200'
100' | 250'
225'
200'
125'
100'
100'
75'
65'
50'
40'
30'
50'
50'
50' |
| 3/4" | PTL0.75BK | 1/2" | 1 1/4" | 250' | 75' |
